Microchip WBZ450 Curiosity
Jump to navigation
Jump to search
This article describes specifics for the Microchip WBZ450 Curiosity evaluation board. It can be used to test & verify Microchip PIC32CX-BZ2 device support.
Minimum requirements
- J-Link software V7.96m or later
Preparing for J-Link
- Connect the J-Link to the SWD header (J10).
- Power the board via the USB jack of the break out board (J7).
- Verify the Connection with e.g. J-Link Commander. The output should look as follows:
Example Project
The following example project was created with the SEGGER Embedded Studio project wizard and runs out-of-the-box on the Microchip WBZ450 Curiosity. It is a simple Hello World sample linked into the internal flash.
SETUP
- J-Link software: V7.96m
- Embedded Studio: V8.12a
- Hardware: Microchip WBZ450 Curiosity
- Link: File:Microchip WBZ450 Curiosity TestProject ES V814.zip
