This article describes specifics for the Renesas EK-RA4C1 evaluation board.
Preparing for J-Link
- Connect the board to host computer J-Link to SWD/JTAG connector (CN401).
- Apply 3.3V to power connector (CM303).
Select R7FA4C1BD as target MCU.
- Verify the Connection with e.g. J-Link Commander. The output should look as follows:
Example Project
The following example project was created with the SEGGER Embedded Studio project wizard and runs out-of-the-box on the EK-RA4C1.
It is a simple Hello World sample linked into the internal flash.
SETUP
- Embedded Studio: V8.24
- Hardware: Renesas EK-RA4C1
- Link: File:Renesas EK-RA4C1 TestProject ES V824.zip
